The Anesthesia Machine

The Anesthesia machine is through the mechanical circuit to the anesthetic into the alveoli of the patient, the formation of anesthetic gas partial pressure, disseminated to the blood, the central nervous system directly inhibitory effect, thus producing the effect of general anesthesia. Anesthesia machine belongs to semi-open anesthesia device. It is mainly composed of anesthesia evaporation tank, flowmeter, folding bellows ventilator, breathing circuit (including suction and expiratory one-way valves and manual air bag), corrugated pipe and other components.

Send Inquiry

Product Description

1. Product Introduction of The Anesthesia Machine

The Anesthesia machine is portable and applicable, which can directly use air and oxygen as carrier gas, and can carry out auxiliary breathing and controlled breathing to meet various surgical requirements.

Here's how it works: After the patient is induced, the air anesthesia machine is connected to a closed mask or endotracheal tube. During inhalation, the anaesthetic mixture enters the patient through an open suction valve; On exhalation, the exhalation valve opens, while the inspiratory valve closes, exhaling the exhaled air. Folding bellows are available when assisted or controlled breathing is used. Press down on inhalation and pull up on exhalation to ensure adequate ventilation for client. At the same time, the ether switch is adjusted according to actual needs to maintain a stable level of anesthesia.

2. Product Parameter (Specification) of The Anesthesia Machine

Part of Anesthesia
Product Name The Anesthesia machine
Main body High-strength engineering plastic rack, light, beautiful
and corrosion resistant
Scope of application adult, child
Gas source O2: 0.28~0.6MPa N2O: 0.28~0.6MPa
Flow meter O2 : 0.05~10L/min N20: 0.05~10L/min
O2 N2O linkage and N2O Stopper When using nitrous oxide, oxygen concentration>25%;
When the oxygen pressure<0.2Kpa, the flow of nitrous
oxide would be cut off.
Flow rate of rapid oxygen supply 25~75L/min
Low oxygen pressure alarm There will be sound alarm when the oxygen pressure
< 0.2MPa
Vaporizer It has the function of automatic compensation based on
pressure, temperature, and flow rate. The regulation
range of evaporator concentration is 0~5 vol%. Among
Halothane,Enflurane, Isoflurane and Sevoflurane, one
can be chosen for application as required by the
customer. And vaporizers that are imported with original
packaging are also available.
Respiratory circuit working mode: all-close, semi-close, semi-open
APL≤12.5 kPa
Respiratory Bellows bellows for adults, tidal volume range:0~1500 ml
bellows for children, tidal volume range:0~300 ml
anyone can be chosen for application as required by
the customer
Display mode High-definition 5.7” LCD screen display

3. Product Feature And Application of The Anesthesia Machine

When using a The Anesthesia machine, it forces the anaesthetic mixture into the patient's circuit and respiratory system to receive both exhaled and fresh air. The anesthesiologist can adjust the tidal volume, respiratory rate, inhalation/exhalation ratio and minute ventilation according to the patient's condition. Adjust the ventilation pattern to meet the various needs of the patient

4. Product Details of The Anesthesia Machine

5. Product Certification of The Anesthesia Machine

Company Certification

Company Profile

Company Exhibition

6. Deliver,Shipping And Serving Of The Anesthesia Machine

Shipping Method Shipping Terms Area
Express TNT /FEDEX /DHL/ UPS All Countries
Sea FOB/ CIF /CFR /DDU All Countries
Railway DDP/TT Europe Countries
Ocean +Express DDP/TT Europe Countries /USA/Canada/Australia /Southeast Asia /Middle East

7. FAQ of The Anesthesia Machine
